ICE ZIPSCAN IS-2210 1D BARCODE SCANNER,USB,CABLE,STAND

Specification

Physical Parameters Dimensions: 83mm*70mm*172mm Weight: 128.5g Material: ABS+PC Cable Length: 2M

Opera�ng Temperature: -20~ 50 Rela�ve Humidity: 5% ~95% RH(Non-condensing) Shock Resistance: Withstands mul�ple �mes 1.5 meters drops to concrete Storage Temperature: -40 ~70 Environmental Parameters Electronic Parameters Working Voltage: DC5V±1% Opera�ng Current: 85mA.

Performance Parameters

Precision: ≥3mil

Scan Tpye: Single Laser Scan Speed: ≥150 times/s

Light Sources: 650nm laser (Safe visible laser diode)

Depth of scan field: 10-280mm(0.33mm, PCS90%)

Error Rate: 1/5million Interface : USB-HID, USB-COM, PS2, RS232

Supported Symbologies: UPC- A, UPC-E, EAN-13, EAN-8, Codabar, Code 39, Code 39 Full ASCII, China Post, Plessey, MSI, Code 93, Code 128, Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5, Code 11, ISBN, ISSN, Code 32(Italian pharm code), Code 39 extended, GS1-128 and ITF-14, SISAS, GS1 Omnidirectional, GS1 Limited, Aviation25, RSS 14.

Scan Angle: Yaw 55°, Rota�on 30°, Pitch 65°

Scan Mode: Manual/Continuous/Automatic Scintillation /Automatic Induction Scanning
